Products
Orion Italia provides a complete range of protection and control products also including industrial automation solutions. From feeders to transformers, to motors and beyond, our instruments provide enhanced reliability and efficiency. The protection and control devices also measure and collect data from the power system in order to support all operators in the energy management of their assets.
Our products are built to meet a wide variety of demanding application environments, from industrial facilities to petrochemical or mining plants, as well as urban utilities and datacenters.
Our protection and devices metering
Temperature Control
Dry insulated Current transformer
- Cable/busbar transformers
- Insulation levels 0.72/3 kV (r.m.s.)
- Rated frequency 50/60 Hz
- Primary current up to 4000 A
- IP20
- Working temperature -10 ÷ +70 °C
- Class on request** 5P10 / 5P15 / 5P20 / 0,5 / 0,2 / 0,2 S
- Secondary current 1 A / 5 A (other currents on request)
- Inner diameters available: 60 mm - 80 mm - 110 mm - 160 mm - 200 mm
- According to IEC 61869-2 standards
- Dry insulation
- Self-extinguishing plastic case
- Indoor use
- Suitable for protection or measurement applications
** depending on the ratio and performance
